Zhejiang Jiangshan Hengli Hluav Taws Xob Co., Ltd. Yog tias koj yuav mus lag luam wholesale vpi qhuav hom transformer ua nyob rau hauv Suav teb, txais tos kom tau txais pricelist los ntawm peb lub hoobkas. Tag nrho cov khoom customized yog nrog cov khoom zoo thiab tus nqi qis.
Peb xa 1 chav tsev ntawm 100kVA H chav kawm VPI qhuav hom transformers rau Suav teb xyoo 2020.Qhov muaj peev xwm ntawm lub tshuab hloov pauv yog 100kVA. Thawj qhov voltage ntawm lub transformer yog 10.5kV thiab theem nrab voltage yog 0.4kV.
Qhov no yog VPI qhuav -hom transformer. Nws cov coil windings tau ntim tag nrho nrog H-chav kawm 220℃siab- ntawv rwb thaiv tsev kub. Cov khoom siv rwb thaiv tsev no muaj kev ua haujlwm zoo dielectric, ntxiv rau qhov tsis tshua muaj thermal expansion coefficient. Cov ntawv laminated rwb thaiv tsev nta H-qib superior tshav kub. Nws muab cov khoom dielectric zog thiab txhim khu kev qha mechanical stability, thiab ua kom zoo heev mechanical kev ua tau zoo txawm nyob rau hauv siab - kub los yog ntub dej ua hauj lwm ib puag ncig.
Cov ntaub ntawv Technical
|
Yam khoom |
Technical Specification |
|
Rated Peev Xwm |
100 kVA ua |
|
Theem |
3 Phase |
|
Thawj Rated Voltage |
10.5 kV 10 |
|
Secondary Rated Voltage |
0,4kv ua |
|
Ntau zaus |
50Hz / 60Hz yeem |
|
Rwb thaiv tsev Class |
H chav kawm (220 degree) |
|
Cov khoom siv rwb thaiv tsev |
Rwb thaiv tsev ntawv, VPI Vacuum Siab Impregnated |
|
Cov khoom siv winding |
Ntshiab tooj liab / Aluminium yeem |
|
Cov khoom siv tseem ceeb |
Grain -Silicon Steel Sheet |
|
Txoj kev txias |
AN / AF (Natural Air / Forced Cua Txias) |
|
Temperature Rise Limit |
125K |
|
Tsis muaj -load Loss |
280 W |
|
Load poob (75 degree) |
1480 W |
|
Tsis muaj -load Tam sim no |
2.2% |
|
Luv Circuit Court impedance |
4.0% |
|
Kev nyab xeeb qib |
C2 |
|
Environmental Qib |
E2 |
|
Hluav taws kub Resistance Qib |
F1 |
|
Ua haujlwm Ambient Kub |
-25℃~ +50 degree |
|
Qhov siab |
Tsawg dua los yog sib npaug rau 1000m (siab dua qhov siab customized) |
|
Lub suab nrov |
Tsawg dua lossis sib npaug li 58 dB |
|
Qib tiv thaiv |
IP00 / IP20 / IP23 yeem |
|
Executive Standard |
IEC 60076-11, GB / T 1094 |
|
Txoj kev teeb tsa |
Sab hauv pem teb Mounted |
|
Kev ua neej nyob |
Tshaj 30 Xyoo Tsim Kev Pabcuam Lub Neej |
|
Kev Pabcuam Kev Cai |
Voltage piv, enclosure, xim, logo customization |
Cov cheeb tsam thov & qhov zoo
Peb 100kVA VPI qhuav hom transformer txais siab heev Nqus Siab Impregnated manufacturing khoom siv tes ua, zoo suited rau sab hauv tsev fais fab kev faib, muaj chaw, lag luam complexes thiab tshiab zog txhawb zog mov systems. Sib txawv ntawm cov pa roj puv transformers, qhov qhuav no - hom chav ua haujlwm yam tsis muaj cov roj insulating, ua rau xoom roj to txaus ntshai, kev nyab xeeb hluav taws zoo dua thiab eco- kev ua haujlwm zoo rau kev ua haujlwm thoob ntiaj teb.
Product Structure & Design Highlights
Chav tsev no nta ntsuas muaj peev xwm 100kVA, thawj qhov hluav taws xob 10.5kV thiab theem nrab voltage 0.4kV, kho kom haum rau qhov tshwj xeeb voltage hloov dua siab tshiab rau kev siv tshuab thiab ntawm -chaw fais fab chaw. Tag nrho cov winding coils yog qhwv nrog siab -qib H Class 220℃rwb thaiv tsev ntawv. Tom qab ntau -lub sij hawm lub tshuab nqus tsev siab impregnation curing, lub windings muaj cov qauv nruj, zoo heev kub tsis kam, dielectric zog thiab anti- luv luv Circuit Court muaj peev xwm, slowing down thermal aging thiab ncua kev pab cuam lub neej nyob rau hauv tas li hnyav{10}} lub luag hauj lwm ua hauj lwm.
Cov tub ntxhais transformer txais siab permeability grain - taw qhia silicon steel ntawv, uas zoo heev txo tsis muaj -load poob, tsis muaj -load tam sim no thiab ua haujlwm kub tsim. Nrog optimized winding layout, nws ua tiav tsis tshua muaj suab nrov, ruaj khov voltage tso zis thiab zoo zog txuag nyhuv. Nws ua tau raws li qib C2 kev nyab xeeb, qib E2 ib puag ncig thiab qib F1 tiv thaiv hluav taws, muaj peev xwm ua haujlwm ruaj khov hauv cov av noo, plua plav thiab qhov kub thiab txias - hloov pauv hnyav ua haujlwm.
Tus qauv tsim-nyob rau hauv kev tswj qhov kub thiab txias kom paub tseeb- lub sijhawm ntsuas kub ntsuas kub, ntsuas kub dhau, tsis siv neeg cua txias thiab kev tiv thaiv ntau dhau. Kev tsim qauv tsim kom txuag tau qhov chaw teeb tsa, txo qis kev ua haujlwm tu txhua hnub thiab txo qis dua - lub sijhawm ua haujlwm siv nyiaj.
Kev kho kom haum
Tag nrho cov khoom yog tsim nyob rau hauv raws li IEC thoob ntiaj teb cov qauv, nrog ntshiab tooj liab winding thiab txhuas winding xaiv rau txawv project pob nyiaj siv. Kev cai voltage piv, tiv thaiv enclosure thiab deg kho yog muaj rau tus kheej OEM kev pab cuam.Optional integrated kub xyuas thiab digital kev sib txuas lus interfaces txhawb cov ntse daim phiaj compatibility thiab kwv yees txij nkawm cov tswv yim.
Lub Hoobkas muaj peev xwm
Peb muab:
- Tus nqi tsim khoom ncaj qha: Hoobkas- ncaj qha (tus nqi zoo tshaj rau 100% upfront). Hla tus neeg nruab nrab thiab tos ntev.
- MOQ: 1 unit - hloov pauv kev koom tes
- Cov khoom lag luam loj muaj, xa khoom sai
- Kev Pabcuam: Tsis muaj kev sib tw, tsis muaj kev ncua, ncaj qha rau cov haujlwm ntiag tug.
- Kev soj ntsuam zoo. Npaj rau koj cov mines & factories hauv koj lub tebchaws.
- Standard ntau lawm lub sij hawm: 15 hnub
- Tsom ntsoov rau Suav fais fab transformer mov nrog ruaj khov zoo thiab ua raws li ntau tus qauv thoob ntiaj teb.
- Cov khoom siv hluav taws xob, cov neeg teeb tsa, thiab EPC cov neeg cog lus tau txais tos rau kev koom tes ntev -.
